Flowell’s Straightening Vanes

Precision in Design

At Flowell, we are dedicated to crafting high-quality Straightening Vanes that elevate the performance and accuracy of your piping systems. These specially engineered vanes are strategically positioned upstream of an orifice plate to mitigate flow disturbances originating from upstream piping configurations or valves.

Versatile Solutions for Every System

Recognizing the diverse needs of piping systems, Flowell produces both line-mounted and flanged models of Straightening Vanes. This versatility ensures compatibility and flexibility in installation, with line-mounted models suitable for internal piping installation and flanged models securely positioned between upstream pipe flanges.

Top-Grade Materials for Durability

Quality matters, and at Flowell, we use only top-grade materials to ensure the durability and longevity of our Straightening Vanes. Our product range includes carbon steel and 304 and 316 stainless steel options, providing solutions that withstand environmental conditions and the corrosiveness of transported fluids.

Compliance with Industry Standards

Adhering to the highest industry standards, every Flowell Straightening Vane is built to meet API 14.3 and ISO 5167 requirements. Stringent quality control measures are implemented throughout manufacturing, guaranteeing that our products consistently meet or exceed your expectations.

Installation Simplicity and Security

Flowell’s flanged model offers easy installation between two pipe flanges, ensuring a secure and leak-free connection. Meanwhile, our line-mounted models simplify installation by being secured inside the piping with set screws threaded through the exterior wall, eliminating the need for additional fittings and minimizing the risk of leaks or pressure loss.

Improved Performance for Efficient Operations

Integrating Flowell Straightening Vanes into your piping systems significantly enhances flow conditions, reduces pressure drop, and minimizes disturbances. Placing our Straightening Vanes upstream of an orifice plate promotes a uniform and stable flow profile, leading to more accurate and reliable flow measurements, ultimately improving efficiency, cost savings, and overall productivity.

Unparalleled Customer Support

In addition to our exceptional products, Flowell is committed to providing unparalleled customer service and technical support. Our team of experienced professionals is always ready to assist with inquiries, concerns, or customization needs, fostering strong relationships with clients and ensuring prompt and efficient support throughout their journey with us.

Trust Flowell for Enhanced Performance

Flowell Straightening Vanes are the ideal solution to boost the performance and accuracy of your piping systems. With the ability to minimize flow disturbances and a range of models, materials, and installation options, Flowell has the right solution for your specific project requirements. Trust Flowell for all your Straightening Vane needs and achieve optimized performance and accuracy in your piping systems.
